Crosslinked PE Foam Production Line

Click here for Russian Language translation.
Click here for Spanish Language translation.
Chemically Cross-linked PE Foam Sheet Production Line is to produce a very fine closed-cell structured, chemically cross-linked Polyethylene foam sheet, in continuous roll, with smooth, aesthetic surface on both sides from Polyethylene a cross-linking and blowing agents, and some other purpose additives.

Compared to non-cross-linked Polyethylene foam, Chemically Cross-linked-PE foam offers longer life of the product, better thermal stability and insulating properties, which makes chemically cross-linked PE foam serve variety of industries.
Product:
Crosslinked PE Foam Production Line

detailed images:
Crosslinked PE Foam Production LineCrosslinked PE Foam Production Line Crosslinked PE Foam Production LineCrosslinked PE Foam Production Line Crosslinked PE Foam Production LineCrosslinked PE Foam Production Line Crosslinked PE Foam Production LineCrosslinked PE Foam Production Line

Applications:
A. Characteristics of XPE Foam Sheet
  • Excellent Insulation Materials (Cold-Warm)
  • Excellent Ventilation and Stepping and Knocking Sound Insulations
  • Great Lightness
  • Not Sensitive to Vapor
  • Excellent Chemical Resistance
  • Insects and Rodents protection
  • Thin, Flexible Material
  • Tailor-made Solution
  • Dyes are applicable
  • Easy to Laminate
  • No Hazard to Health
B. Applications Of Product
  • Building and Construction
  • Protection and Packaging
  • Sports and Leisure
  • Automotive and Insulation
Specifications:


Model No. RYF-X150 RYF-X200
Extruder's Screw (mm) 150 200
Capacity (kg/hr) 170 250
Width (mm) 600-1500 1000-2000
Thickness (mm) 3-15 3-20
Density (kg/m3) 23-200 23-200
