XPS Foam Board Line

XPS FOAM BOARD LINE

XPS foam board has value in a variety of building and insulating applications especially in harsh and unique environments. In many of these applications such as cold storage, frost protected shallow foundation or protected roof membrane assemblies, XPS foam board is the only recommended or approved material as a result of its durable qualities.

The XPS industry has demonstrated the ability to recycle and reuse post-industrial as well as post-consumer polystyrene in its products.

Procedure of XPS Foam Board:

Raw materials dosing and feeding unit
Raw material melting unit
Expanding gas injection
Board forming unit
Board cooling
Longitudinal cutting
Edge cutting and forming
Board stacking
Packing with polyethylene film

Applications:

Characteristics Of Product:

Excellent insulation & durability
Waterproof & Moisture proof protection
High mechanical resistance
Excellent compressive strength
Low thermal conductivity
100% recyclable & reusable

Applications Of Product

Insulation for roofing, wall and foundation
Insulation for under roads/railways/airport runways
Advertising displays, signs & decorative raw material
Waterproof protection
Support for tile installation
Home and industrial applications
Concrete Deck/Ballasted Waterproofing
Concrete Wall Forming Systems
Interior & Exterior Foundation Walls

Specifications : Single Screw XPS Technology

Model No.	RYF-XPS 120-150	RYF-XPS 150-200<
Capacity (Kg/hr)	Max.450Kg/hr	Max.750Kg/hr
Sheet Width	600mm, 900mm, 1200mm	600mm, 900mm, 1200mm
Sheet Thickness	20-80mm	30-120mm
Density	32-45Kgs/m3	32-45Kgs/m3

Specifications : Twin Screw XPS Technology

Model No.	RYF-XPS 70/150	RYF-XPS 110/250
Capacity (Kg/hr)	Max.550kg/hr	Max.1500kg/hr
Sheet Width	600mm, 900mm	600mm, 900mm
Sheet Thickness	20-90mm	80-200mm
Density	22-45kg/m3	22-45kg/m3

Innovative Extruded

FOAM SOLUTIONS

FOAMTECH KOREA creates custom-engineered closed cell of Polyethylene, Polypropylene and other engineered foams using proprietary formulations that result in exceptional performance. These foams feature excellent physical properties for thermal insulation, shock absorption, and sound dampening. Our foam is soft, smooth, lightweight, and flexible, yet tough enough to resist scuffing and multiple impacts.

Our Expertise

Foamtech Korea, is an ISO 9001:2015 certified innovative foam manufacturer and designer of custom-engineered foam extrusions for an array of markets, including insulation, protective packaging, pipe insulation for HVAC and plumbing, aducational material, medical product and furniture. We employ leading-edge technology to create unique foam shapes and formulations and pride ourselves on adapting to your business needs.
